- CRISTALY® paintable
Description
The 16 mm MINILEDs represent a veritable concentration of technology.
The exceptional hole/lumen/volume ratio is a global one of a kind, and was created exclusively by 9010novantadieci to ensure the best lighting and maximum energy savings.
The MINILED models feature easy manutentability from the light hole, with the innovative possibility of choosing between 4 distinct optical lenses (20°, 30°, 40°, 50°) that are easily interchangeable, even when the product has already been installed on site, producing different light angles.
Furthermore, they also facilitate the choice of luminous intensity as they can be driven at different currents: by selecting the right driver, the MINILEDs can be driven up to 900mA, equal to 11W of power.
MINILED and MICROLED: let yourself be enchanted!
Technical specifications
Variants
| Code | Electrical part | Description | Power supply | Driver |
|---|---|---|---|---|
4249S-30187 | LED - 17W - MAX 700mA | 3000K - 1680lm - CRI90 - Lens 20° | Remote driver, not included | |
4249S-27187 | LED - 17W - MAX 700mA | 2700K - 1620lm - CRI90 - Lens 20° | Remote driver, not included | |
4249S-40187 | LED - 17W - MAX 700mA | 4000K - 1740lm - CRI90 - Lens 20° | Remote driver, not included | |
4249S-30188 | LED - 17W - MAX 700mA | 3000K - 1680lm - CRI90 - Lens 30° | Remote driver, not included | |
4249S-27188 | LED - 17W - MAX 700mA | 2700K - 1620lm - CRI90 - Lens 30° | Remote driver, not included | |
4249S-40188 | LED - 17W - MAX 700mA | 4000K - 1740lm - CRI90 - Lens 30° | Remote driver, not included | |
4249S-30189 | LED - 17W - MAX 700mA | 3000K - 1680lm - CRI90 - Lens 40° | Remote driver, not included | |
4249S-27189 | LED - 17W - MAX 700mA | 2700K - 1620lm - CRI90 - Lens 40° | Remote driver, not included | |
4249S-40189 | LED - 17W - MAX 700mA | 4000K - 1740lm - CRI90 - Lens 40° | Remote driver, not included | |
4249S-30190 | LED - 17W - MAX 700mA | 3000K - 1680lm - CRI90 - Lens 50° | Remote driver, not included | |
4249S-27190 | LED - 17W - MAX 700mA | 2700K - 1620lm - CRI90 - Lens 50° | Remote driver, not included | |
4249S-40190 | LED - 17W - MAX 700mA | 4000K - 1740lm - CRI90 - Lens 50° | Remote driver, not included |
